Scanning Mode

Progressive

Lens

30x, f=4.42mm ~ 132.6mm, F1.8 ~ F2.8

Digital Zoom

8x

Minimum Illumination

0.5 Lux @ (F1.8, AGC ON)

Shutter

1/30s ~ 1/10000s

White Balance

Auto, VAR, Manual,
 One Push, Indoor, Outdoor

Backlight Compensation

Support

Digital Noise
 Reduction

2D & 3D Digital Noise Reduction

SNR

≥55dB

Horizontal FOV

60.7° ~ 2.28°

Vertical FOV

34.1° ~ 1.28°

Pan Angle

±170°

Tilt Angle

-30° ~ +90°

Pan Speed

1.7° ~ 100°/s

Tilt Speed

1.7° ~ 69.9°/s

Image Flip

Support

Image Freeze

Support

Preset Position

255

Preset Accuracy

0.1°

Audio Features

Microphone Array

Built-in dual microphones, 100Hz to 16KHz frequency response

Audio Input

Support LINE IN audio input

Audio Output

Support LINE OUT, HDMI, USB and other audio output

USB Features

Operate System

Windows 7/8/10, Mac OS X, Linux, Android

Color System /
 Compression

YUY2/MJPEG/H.264

USB Audio

Support

USB Video
 Protocol

UVC 1.1/UVC 1.5

UVC PTZ Control

Support

Network Features

Video Compression

H.264/H.265

Video Stream

First Stream,
 Second Stream

First Stream Resolution

1920x1080, 1280x720, 1024x576, 960x540, 640x480, 640x360

Second Stream Resolution

1280x720, 1024x576, 720x480, 640x360, 480x272, 320x240, 320x180

Video Bit Rate

32Kbps ~ 20480Kbps

Bit Rate Control

CBR, VBR

Frame Rate

1fps ~ 60fps

Audio Compression

AAC

Audio Bit Rate

96Kbps, 128Kbps, 256Kbps

Protocols

NDI, TCP/IP, HTTP, RTSP, RTMP/RTMPS, ONVIF, DHCP, SRT, Multicast

Interfaces

LINE IN Interface

1 x LINE IN: 3.5mm Audio
 Interface

LINE OUT Interface

1 x LINE OUT: 3.5mm Audio
 Interface

Communication Interface

1 x RS485: 2pin phoenix port, Max Distance:
1200m, Protocol: VISCA/
 Pelco-D/Pelco-P

1 x RS232 IN: 8pin Min DIN, Max Distance: 30m, Protocol: VISCA/Pelco-D/
 Pelco-P

1 x RS232 OUT: 8pin Min DIN, Max Distance: 30m, Protocol: VISCA network use only

Network Interface

1 x LAN: 10M/100M Adaptive Ethernet Port

HDMI Interface

1 x HDMI: Version 1.3

3G-SDI Interface

1 x 3G-SDI: BNC type,
800mVp-p, 75Ω. Along to SMPTE 424M standard

USB Interface

1 x USB 3.0: Type A

Power Jack

JEITA type (DC IN 12V)
