Video System

1080P/60, 1080P/50，1080/P30, 1080P/25，720P/60, 720P/50

Sensor

1/2.8 inch, CMOS,

Effective Pixel: 2.07M

Scanning Mode

Progressive

Lens

12x, f=3.5mm ~ 42.3mm, F1.8 ~ F2.8

Digital Zoom

16x

Minimum Illumination

0.5 Lux @ (F1.8, AGC ON)

Shutter

1/30s ~ 1/10000s

White Balance

Auto, Indoor, Outdoor,
 One Push, Manual, VAR

Backlight Compensation

Support

Digital Noise
 Reduction

2D & 3D Digital Noise
 Reduction

Signal Noise
 Ratio

≥55dB

Horizontal Angle of View

72.5° ~ 6.9°

Vertical Angle of View

44.8° ~ 3.9°

Horizontal Rotation Range

±170°

Vertical Rotation Range

-30° ~ +90°

Pan Speed
 Range

2.7° ~ 35.7°/s

Tilt Speed
 Range

2.7° ~ 31.5°/s

H & V Flip

Support

Image Freeze

Support

Number of
 Preset

255

Preset Accuracy

0.1°

Network Features

Video Compression

H.264/MJPEG

Video Stream

First Stream,
 Second Stream

First Stream Resolution

1920x1080, 1280x720,
1024x576, 960x540,
 640x480, 640x360

Second Stream Resolution

1280x720, 1024x576,
720x576 (50Hz),
720x480 (60Hz),
720x408, 640x360,
480x272, 320x240,
 320x180

Video Bit Rate for First Stream

32Kbps ~ 20480Kbps

Video Bit Rate for Second Stream

32Kbps ~ 6144Kbps

Bit Rate Control

CBR, VBR

Frame Rate

50Hz: 1fps ~ 50fps,
 60Hz: 1fps ~ 60fps

Audio Type

AAC

Audio Bit Rate

96Kbps, 128Kbps,
 256Kbps

Protocols

TCP/IP, HTTP, RTSP,
RTMP(S), ONVIF, DHCP,
 Multicast, etc.

USB Features

Operate System

Windows 7, Windows 8,
Windows 10, Mac OS X,
 Linux, Android

Color System / Compression

MJPG/YUY2/H.264

Video Format

1. YUY2:1080P@60fps (max.)
2. H.264 AVC:

1080P@60fps (max.)

1. H.264 SVC:
    1080P@60fps (max.)
2. MJPEG: 1080P@60fps (max.)

USB Audio

Support

USB Video
 Communication Protocol

UVC 1.1

UVC PTZ

Support

Input/Output Interface

Network Interface

1 x NET: 10M/100M
 Adaptive Ethernet Port

USB Interface

1 x USB 3.0: Type-C

LINE IN Interface

1 x LINE IN: 3.5mm Audio Interface

Communication Interface

1 x RS232: 8pin Min DIN, Max. Distance: 30m, Protocol: VISCA/Pelco-D/
 Pelco-P

1 x RS485: 2pin phoenix port, Max. Distance: 1200m, Protocol: VISCA/

Pelco-D/Pelco-P

HDMI Output Interface

1 x HDMI 1.4b

Power Jack

JEITA type (DC IN 12V)

/USB Type-C (DC IN 5V)

/PoE

Physical Parameter

Input Voltage

DC 12V/DC 5V
 /PoE (802.3af)
