TOA CM-760 Separate Type Ceiling Speaker
| Rated Input | 6 W |
|---|---|
| Rated Impedance | 1.7 kΩ (6 W), 3.3 kΩ (3 W), (6.7 kΩ (1.5 W), 13 kΩ (0.8 W): Internal wiring must be changed) |
| Sound Pressure Level | 90 dB (1 W, 1 m) |
| Frequency Response | 100 - 16,000 Hz |
| Speaker Component | 12 cm dynamic cone-type speaker |
| Dimensions for Fixing Hole | φ150 (mounting hole) × 50 (ceiling thickness) mm |
| Speaker Mounting Method | Spring catch |
| Applicable Cables | 600 V Vinyl-insulated cable (IV wire or HIV wire) Solid copper wire: φ0.8 - φ1.2 mm 7-core twisted copper wire: 0.75 - 1.25 m㎡ |
| Connection | Push-in connector (Bridging and branch connections possible.) |
| Finish | Grille: Fire-resistant, high-impact styrene resin (resin material grade: UL94 V-O or its equivalent), black |
| Dimensions | 215 (W) × 134 (H) × 89 (D) mm |
| Weight | 630 g |
| Applicable Panel | CP-70 series panel (option): CP-73, CP-77 |
Powered by Froala Editor
ยี่ห้อ : TOA
รุ่น : CM-760
รับประกัน : 1 ปี
ราคาพิเศษ / ขอใบเสนอราคา : anysound.co@gmail.com, Line : @anysound, โทร 096-786-2526
